Wholesale Wall Mounted FTTH Termination Box High Accuracy Waterproof Optical
Product Overview of FTTH Termination Box:
This fiber optic distribution box are used in the terminal link of FTTH access system,specially suitable for pole and wall mounting application.In the optical fiber transmission network,splitter distribution box is the ideal equipment between optical node and terminal.
In the FTTx communication network system, the splitter box serves as the terminal connecting the feeder cable and the drop cable. The optical fiber connecting, dividing and dividing can be completed in this box, and also provides a solid protection and management for FTTx network construction.
8/16 Core PLC Splitter distribution box is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.
Features of FTTH Termination Box:
- Material: PC,wet-proof,water-proof,dust-proof,anti-aging, protection level up to IP68
- Cable,pigtails,patch cords are running through own path without disturbing each other, cassette type SC/LC/PLC adaptor installation, easy maintenance.
- Distribution panel can be flipped up, feeder cable can be placed by expression port, easy for maintenance and installation.
- Cabinet can be installed by the way of wall-mounted or poled-mounted, suitable for both indoor and outdoor uses.
- Outdoor optical cable fixing, leather line optical cable fixing, adapter fixing, and fast field connector fixing. Pull-off force is greater than 50N, fixed and reliable.
- Single-core sheathed optical cable access to single-port output inside and outside the wall, indoor and outdoor dual-core sheathed optical cable access to dual-port output, outdoor
- Cable is connected to the multi-skin line output, and is used in multiple occasions and multiple demand environments.
- The wall outlet termination box is easy to operate and has low construction intensity.
- The wall outlet termination box is designed with a large arc shape to ensure that the fiber optic cable placed in it will not be damaged when subjected to external forces, affecting the quality of communication.
- For home or work area (FTTD) fiber interface.
- Connecting type: SC, LC with common model adapters.
- Using high-quality ABS material, has a certain fire resistance.
- With dustproof device to prevent dust from entering.
- Scope of application 3.1 × 2.0mm drop cable or patch cable
- PC+ABS material used ensures the body strong and light
- Wet proof, water proof, dust proof, anti aging
- Easy installations: Ready for wall mount installation kits provided
- Space saving: Double layer design for easier installation and maintenances
Applications of FTTH Termination Box:
- FTTx Deployments(GPON/BPON/EPON)
- CCTV/CATV Links
- Access/Metro Networks
- Telecommunication Network
- For home, hotel, office and buildings fiber network cabling system
- Audio signals, network system, data, image transmission system, CATV cable series
- The terminal box can be used as an indoor connector box
- Can be divided into cable handover box and cable handover box.
- They are used in the user's front end wiring.
- Networking of electronic terminal devices
- For indoor optical cable
Technology Specification:
| Name | Fiber termination box |
| Material | PC+ABS |
| Model | DH-A1-16R |
| Colour | Black |
| Size | L |
| Feature | Inlet Cable Size:12-15mm Inelt:1uncut cable port and 2cable glands |
| Moq | 200PCS |
| Weight | 1.22KG |
| Dimension | 290*210*82 |
Details of FTTH Termination Box:
Packaging:
FAQ:
Q1. Could you offer samples?
Yes, samples are accepted.You need place sample order to us, and we will reduce from bulk order.
Q2. What's the delivery time for sample order?
Normally about 3days after confirmation.
Q3. What's the delivery time for bulk order?
Normally 5-10 days depends on products and order quantities.
Q4. Could you do design for us?
Yes, we provide customized service and can do artworks including printing, logo etc. for you.
Q5. What's the payment terms?
TT, WesternUnion, Escrow(secure payment), Trade assurance, Cash, etc.
Q6. Can I use my own LOGO and design on products?
YES, OEM is welcomed.
Q7. How to send the goods?
Usually deliver by courier, like DHL, UPS, FedEx; also bulk cargo by air & sea.
Q8. Certificates:
ISO9001:2015, CE, China Radio and television equipment network access certification
Q9. Small order available? Order MOQ?
Yes sure, Normally10kms per one specification. For support new customers, we know business always comes from small order.
Q10. Design:
OEM/ODM service available. Cable design and package design also available.You can share us your requirement.
